En este tutorial, aprenderás a hacer lo siguiente:

• Configure a firewall section

• Open VPN

• Filtro MAC



Configure a firewall section

1. From your device's web browser, go to http://my.inseego.

Note: Ensure that your device is connected to the Inseego MiFi PRO M4's Wi-Fi network. For more information, please visit the Connect Devices to Wi-Fi or Connect PC or Mac to Wi-Fi tutorials. Si esta es la primera vez que ingresas a la página de administrador web, la contraseña predeterminada aparecerá en la parte inferior de tu dispositivo. Se te indicará que cambies la contraseña de administrador.


Imagen 1

2. Select the Security menu, then select the Firewall tab.

Imagen 2

3. Edit the desired settings under General Settings and Demilitarized Zone (DMZ).

Imagen 3





Open VPN

1. Select the Security menu, then select the VPN tab.

Imagen 4

2. Enter in OpenVPN Username and Password, then drag and drop or upload OpenVPN Configuration Files.

Note: To automatically connect to the OpenVPN tunnel, select the Auto-Connect VPN switch.

Imagen 5

3. Selecciona Connect.

Imagen 6





Filtro MAC

1. Select the Security menu, then select the MAC Filter tab.

Imagen 7

2. To turn on MAC Filter, select the Enable Filter checkbox next to the desired device, then select the MAC Filter switch on the right side of the screen. Selecciona Guardar.

Note: Devices not selected in the MAC Filter automatically disconnects from the primary Wi-Fi network.

Imagen 8

3. To add a device, select Add. Enter in device's Hostname and MAC address, then select the Enable Filter checkbox. Selecciona Guardar.

Note: To remove a device, select the X icon next to the desired device.

Imagen 9
