Ensamblaje del teléfono

Instalar y quitar la tarjeta SIM y la batería.

INSTRUCCIONES E INFORMACIÓN

If a SIM is not in the device the Missing SIM Icon will display in the Status bar cuando el dispositivo esté encendido.
The SIM Card tray is located under the back cover of the device. To remove the cover, insert your fingernail into the slot at the bottom right side of the cover and lift the back cover.
Slide the locking flap in the direction of the arrow to unlock, and open the slot. Insert the new nano SIM card into the slot with the gold contacts facing down, making sure the cut-off corner is at the top right and then lower the flap of the SIM card slot. Slide the flap in the direction of the arrow to lock it.
To insert a microSD memory card, slide the Tarjeta de memoria into the microSD card holder with the gold contacts facing down and the notched edge going in first. Gently push the card in until it snaps into place.

Importante: SD cards are sold separately. Para prevenir el daño de datos, se recomienda desmontar la tarjeta de memoria antes de quitarla. To unmount your memory card, tap Settings > More > Almacenamiento > Unmount SD Card.
Replace the Back cover, pushing down on both sides from top to bottom until it clicks into place.
