1. From the bottom of the device, use the notch on the left side to lift the back plate up and off the device.



Image 1



2. To remove the battery, gently lift from the notch at the left side of the battery.



Image 2



3. To insert the SIM card, lift the sim cover then put the nanoSIM card into the SIM slot with the gold contacts facing down and the notched edge on the bottom right. When finished, reattach the SIM cover by pressing it into place.



Image 3



4. To insert the battery, line up the gold contacts at the bottom right of the battery with the gold contacts on the device and gently slide in until the battery is in place.



Image 4



5. Reattach the back plate by pressing it into place.



Image 5
